Features:

• High quality ABS engineering plastic bed head and end.
• Automatic lifting guardrail, is safe and reliable, and can be fixed upward and downward.
• LINAK power device.
• Four truckles adopt central control system, which is stable and reliable.

Specifications:

• supply voltage: AC220V±20V
• power frequency: 50Hz± 1Hz
• Working Voltage: DC 24V
• Total power input: ≥450VA
• Working environment temperature: 5 ℃ ~ 40 ℃
• Relative humidity: ≤ 85%
• Atmospheric pressure: 86KPa ~ 106KPa
• Fuse: 1A
• Shell protection grade: IPX4
• Maximum test load: 4000N
• Safe working load: 1700N
• Hanging load of the infusion pole: <2kg>
• Ajustable range of the infusion: ≥ 300mm
• Maximum vertical length of the soft link: ≤ 280mm vertical axis corresponds to the bed body
• Angle of Back Section: 0 °–65 °(±5 °)
• Angle of Leg Section: 0 °–35 °(±5 °)
• Adjustable Height: 475–730mm
